| COLOR CODE - 0805 & LARGER |
| Character |
Significant
Digits |
Capacitance in picofarads |
| Orange |
Black |
Green |
Blue |
Violet |
Red |
Yellow |
| (X0.1) |
(X1.0) |
(X10) |
(X100) |
(X1,000) |
(X10,000) |
(X100,000) |
| A |
10 |
1.0 |
10 |
100 |
1,000 |
10,000 |
100,000 |
1,000,000 |
| B |
11 |
1.1 |
11 |
110 |
1,100 |
11,000 |
110,000 |
1,100,000 |
| C |
12 |
1.2 |
12 |
120 |
1,200 |
12,000 |
120,000 |
1,200,000 |
| D |
13 |
1.3 |
13 |
130 |
1,300 |
13,000 |
130,000 |
1,300,000 |
| E |
15 |
1.5 |
15 |
150 |
1,500 |
15,000 |
150,000 |
1,500,000 |
| H |
16 |
1.6 |
16 |
160 |
1,600 |
16,000 |
160,000 |
1,600,000 |
| I |
18 |
1.8 |
18 |
180 |
1,800 |
18,000 |
180,000 |
1,800,000 |
| J |
20 |
2.0 |
20 |
200 |
2,000 |
20,000 |
200,000 |
2,000,000 |
| • (dot) |
21 |
21 |
21 |
210 |
2,100 |
21,000 |
210,000 |
2,100,000 |
| K |
22 |
2.2 |
22 |
220 |
2,200 |
22,000 |
220,000 |
2,200,000 |
| L |
24 |
2.4 |
24 |
240 |
2,400 |
24,000 |
240,000 |
2,400,000 |
| N |
27 |
2.7 |
27 |
270 |
2,700 |
27,000 |
270,000 |
2,700,000 |
| O |
30 |
3.0 |
30 |
300 |
3,000 |
30,000 |
300,000 |
3,000,000 |
| R |
33 |
3.3 |
33 |
330 |
3,300 |
33,000 |
330,000 |
3,300,000 |
| S |
36 |
3.6 |
36 |
360 |
3,600 |
36,000 |
360,000 |
3,600,000 |
| T |
39 |
3.9 |
39 |
390 |
3,900 |
39,000 |
390,000 |
3,900,000 |
| V |
43 |
4.3 |
43 |
430 |
4,300 |
43,000 |
430,000 |
4,300,000 |
| W |
47 |
4.7 |
47 |
470 |
4,700 |
47,000 |
470,000 |
4,700,000 |
| X |
51 |
5.1 |
51 |
510 |
5,100 |
51,000 |
510,000 |
5,100,000 |
| Y |
56 |
5.6 |
56 |
560 |
5,600 |
56,000 |
560,000 |
5,600,000 |
| Z |
62 |
6.2 |
62 |
620 |
6,200 |
62,000 |
620,000 |
6,200,000 |
| 3 |
68 |
6.8 |
68 |
680 |
6,800 |
68,000 |
680,000 |
6,800,000 |
| 4 |
75 |
7.5 |
75 |
750 |
7,500 |
75,000 |
750,000 |
7,500,000 |
| 7 |
82 |
8.2 |
82 |
820 |
8,200 |
82,000 |
820,000 |
8,200,000 |
| 9 |
91 |
9.1 |
91 |
910 |
9,100 |
91,000 |
910,000 |
9,100,000 |
| Black "A" = 10 pF, Violet "W" = 47,000 pF or .047 mF |
|
